Nanofiltration system nanofiltration unit
A. Nanofiltration system nanofiltration unit product description
Nanofiltration(NF) is a sort of membrane separation technology that is similar to ultrafiltration and reverse osmosis technology. The membrane of nanofiltration system has a molecular weight cut-off ranging from 200 to 1000 and pore size of only several nanometers.
B. Nanofiltration system nanofiltration unit control method
Whole system use full automatically control model, both model can be exchanged accordingly. Sand filter with auto and manual back flush.The RO system automatic flushing at each start-up and shutdown. High water level auto stop, low water level auto start.Pump protected without water.Protected when no power, poor power, larger electrical current, leakage, short circuit.
C.Nanofiltration system nanofiltration unit application treated wastewater.
| Nanofiltration system | |||
| Application | Permeate | Concentrate | Benefits of NF |
| Whey / Whey Permeate | Salty wastewater | Desalted whey concentrate | Allows the recovery of lactose and whey protein concentrate with reduced salt content |
| Textile | Dyes | Water, salts, BOD, COD and color | NF is used to desalt dyes resulting in a higher value product |
| Caustic cleaning solutions | Caustic cleaning solution | BOD, COD, suspended solids, caustic cleaner | Allows caustic cleaning solution to be recycled resulting in reduced cleaning chemical costs |
| Recycle of acid solutions | Acid solution | BOD, COD, calcium, suspended solids, acidic water | Allows acid solution to be recycled resulting in reduced cleaning chemical costs |
| Water | Softened water | Hard water | Potable water production. Softened water reduces scaling on equipment and heat exchange surfaces |
| Antibiotics | Salty waste product | Desalted, concentrated Antibiotics | NF produces high value pharmaceutical products |
Inquiry Guides
To find the most appropriate for your use, please advise the following information ready
· Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
·Product water purpose(drinking, irrigation, industry process or others)
· Feed Water TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
· Power (110/220/380V/415V/460V, 50 or 60 Hz) 3 phase.
· It is necessary to make water analysis reprot for borehole water,lake water, seawater.
· If soure water is tap water no need water analysis report.
Email: Tianna@swroplant.com, Email: Eva@swroplant.com
Mob&WhatsApp&WhatChat: +86 13798883773, +8613532836525
Nano filtration systems based on different capacity and treated water standard or purpose. we will supply the Optimization solution for client.
