Ion exchange water softer system

Industrial water softener machine is a kind of operation and regeneration process of ion exchange softener.When the raw water containing the hardness ions passes through the exchanger resin layer, the calcium and magnesium ions in the water are replaced with the sodium ions in the resin, the resin adsorbs calcium and magnesium ions and the sodium ions enter the water, By removing calcium and magnesium ions in water, the flowing out water reduce hardness is reduced.

Features of ion exchange water softer system

-The cost based on user selection brand component.

-Temperature:5-50℃

-Feed water should not exceed 1,000 ppm TDS

-Capacity：10m3/hr-50m3/hr

-Tank material: Corrosion-resistant glass, 304 stainless steel and carbon steel lined with rubber

-Control mode: time type or flow type

-Product Water hardness：≤0.03mmol/L(Raw water TDS≤400ppm, hardness≤8mmol/L hour)

-Regeneration mode：downstream or countercurrent

-Interface form：Pipe thread / ABS flange

-The valve body material – Runxin brand with small flow resistance, corrosion resistance, anti-scale and anti-impurity, durable, LCD display interface.

-Resin：Purolite brand, Zhenguang brand etc

-Slower flow rate per cu.ft. = better filtration

-2 GPM/cu.ft. = minimum “superior softening”

Benefits of ion exchange water softer system

1. Stable operating conditions, high degree of automation.

2. Advanced program control device, accurate and reliable operation, can replace manual operation, fully realize automatic conversion of all aspects of water treatment.

3.Low energy consumption, high efficiency, and economical operating costs. As the overall design of the softener, the resin’s exchange capacity can be fully utilized. The device uses spray salt and adds a salt pump to reduce energy consumption.

4.Flow-type softened water equipment is compact, small footprint, saving infrastructure investment, easy to use, installation, commissioning, stable operation of parts.

5.Used in various steam boilers, heat exchangers, air conditioners, steam condensers, hot water boilers, direct-fired gas turbines and other machine and systems of circulating water supply.

Parameter table of ion exchange water softer system

Flow L/h	Tank model	Tank size (mm)	Resin quantity (L)	Salt box (L)	Control valve	Unit size(m) L×W×H
15-16m3	3672	Φ900×1800	700	1000	Runxin/Pentair F74A	2.5×1.5×2.5
20m3	4085	Φ1000×2250	900	2000	Runxin/Pentair F77A	2.5×1.5×2.5
25m3	4878	Φ1200×1850	1200	2000	Runxin/Pentair F77A	3×2×3
30m3	4896	Φ1200×2450	1450	2000	Runxin/Pentair F78A3	3×2×3
40m3	6069	Φ1500×2400	1900	2000	Runxin/Pentair F78A3	3×2×3
Factory price of automatic water softener: Hardness is less than 120ppm 25L resin producted water 13T Hardness less than 200ppm 25L resin produced water 10~12T Hardness at 400ppm 25L liters of resin producted water 5~6T.

Haiyuan water softener machine cost is designed for maximum durability and reliability in regards to system malfunction. Haiyuan has more than 10 years of experience in the field of designing water softener systems, with professional service consulting and skilled technical workers.Other advantages that an industrial water softening machine supplier provides include:

Inquiry Guides

To find the most appropriate for your use, please advise the following information ready
· Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
·Product water purpose(drinking, irrigation, industry process or others)
· Feed Water Hardness and TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
· Power (110/220/380V/415V/460V, 50 or 60 Hz) 3 phase.
·  It is necessary to make water analysis reprot for borehole water,lake water, seawater.
·  If soure water is tap water no need water analysis report.

For more information on our available industrial water softener machine cost technologies, contact us now.
