Quartz sand activated carbon filtration system
What is quartz sand filtration system?
It uses quartz sand as a filter medium. Under a certain pressure, the water with higher turbidity is filtered through a certain thickness of granular or non-granular quartz sand, which effectively intercepts and removes suspended solids, organic matter, and colloids in the water. Particles, microorganisms, chlorine, smell and some heavy metal ions, etc., ultimately achieve the effect of reducing water turbidity and purifying water quality.
What is activated carbon filtration system?
The activated carbon filtration can absorb the residual chlorine from source water. To prevent the reverse osmosis membrane from being oxidized and degraded, Meanwhile it also adsorbs pollutants such as small molecular organics leaked from the previous stage. , It has obvious adsorption and removal effect on peculiar smell, colloids and pigments, heavy metal ions, etc., and also has the effect of reducing COD. The SDI value of RO inflow can be further reduced to ensure SDI<5 and TOC<2.0ppm.
Is there any material for sand activated carbon filtration system to choose?
There are FRP, SS304 and carbon steel. Different water sources, raw water quality, and water capacity are different. Haiyuan will choose the most suitable material for users. The quartz sand activated carbon filter will be equipped with control valves according to user needs, and it has automatic forward and reverse flushing. To flush function.
Is there any material for sand-activated carbon filtration system to choose?
There are FRP, SS304 and carbon steel. Different water sources, raw water quality, and water capacity are different. Haiyuan will choose the most suitable material for users. The quartz sand activated carbon filter will be equipped with control valves according to user needs, and it has automatic forward and reverse flushing. To flush function.
Advantage of sand activated carbon filtration system
1).Quartz sand is used as a filter medium to remove particulate impurities such as iron embroidery, silt, colloid, suspended matter visible to the naked eye, etc. in the water.
2).Quartz sand activated carbon filratioon has the advantages of low filtration resistance, large specific surface area, strong acid and alkali resistance, and good pollution resistance.
3).The activated carbon filter has an automatic backwashing function.
4).The activated carbon filters are used in various fields, especially in water purification.
Application range of sand activated carbon filtration system
Quartz sand filter activated carbon filter can be widely used in electronic power, petrochemical industry, metallurgy and electroplating, paper and textile, pharmaceutical dialysis, food and beverage, drinking water, factory and enterprise water, swimming pool. As pre-treatment can better ensure RO feed water, to extend the service life of system.
Why choose Haiyuan sand activated carbon filtration system?
Compact structure.
Selection of filter material is rigorous to better guarantee the quality of the produced water.
3.Our workers are skilled workers who have professional skills can maximize the efficiency of the machine. For example, like the sands filter our technicians will layer by layer of quartz sand to maximize the effect of sand tank filtration.
Please tell us the following information in order to design qand filter activated carbon filtration for you.
How many liters of water do you need per hour? (5000L/H, 10000L/H, etc.)
Do you have source water analysis report or know the water quality?
After treatment, what is the purpose of water?
Do you need to equip a booster pump? If you need, please help confirm the local voltage?
