Sea water desalination treatment system
Containerized 100m3 per day seawater desalination system
Product model: HY-swro100
Fresh water output: 100CMB per day
Electrical control protection level: IP56
Weight: ≈5000Kg (Net weight)
Power: 25KW
Water output standard: in line with national drinking water standards <GB5749-2006>
Product parameters:Sea water desalination treatment system
| HY-SWRO-5m3/hr(100m3/D) | |||
| Flow rate | 100T/day | Recovery rate | 40% |
| Applicable power | 380V/50HZ 3 phase | Rated power | 32.4 KW |
| Feedwater TDS | <45000ppm | freshwater TDS | <600ppm |
| Working pressure | <6Mpa | operating temperature | 5-45℃ |
| Feedwater residual chlorine | <0.1ppm | Feedwater SDI | <5 |
| Feedwater turbidity | <1NTU | Feedwater PH value | 3-10 |
| RO membrane housing | 8040-4 core | RO membrane | 8 piece |
| Equipment specification | 6X1.2X1.65(m) | Net weight | 1500Kg |
| Packing specification(Plywood) | 6.1X1.3X1.68(m) | Gross weight | 1800Kg |
Sea water desalination treatment system functions
1. Overpressure protection for high-pressure pump outlet water. When the outlet pressure of the high-pressure pump exceeds 3.0MPa, the equipment will automatically shut down and sound and light alarms will be issued.
2. Underpressure protection for insufficient inlet pressure of the high-pressure pump. When the inlet pressure of the high-pressure pump is lower than 0.05MPa due to insufficient pretreatment water supply, it will automatically shut down and sound and light alarms will be issued.
3. Equipped with a manual multi-way valve, the sand filter can be filtered, backwashed and forward washed conveniently and quickly as needed.
4. Touch screen control, equipped with Schneider electrical components, the alarm system has manual confirmation and silencing functions.
5. Equipped with a reverse osmosis membrane cleaning system, the reverse osmosis membrane components can be physically cleaned, concentrated water replaced, chemically cleaned and filled with protective fluid.
Applicable power supply: three-phase 220V/60HZ, 380V/50HZ, 440V/60HZ
Water standard: in line with national drinking water standard <GB5749-2006>
200m3pd seawater desaliantion plant 10m3/hr desaliantion system from deep well water.
Inquiry Guides
To find the most appropriate system/machine/plant for your use, please advise the following information ready
· Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
·Product water purpose(drinking, irrigation, industry process or others)
· Feed Water TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
· Iron
· Manganese
· TSS(Total Suspended Solid)
· SDI(Silting Density Index)< 3
· Water must be free from oils and grease
· Chlorine must be removed
· Power (110/220/380V/415V/460V, 50 or 60 Hz) 3 phase.
· It is necessary to make water analysis reprot for borehole water,lake water, seawater.
· If soure water is tap water no need end to us TDS or water analysis report.
