Reverse osmosis drinking water system
Reverse osmosis system in Drinking Water Treatment:
Reverse Osmosis (RO) is a highly effective method for purifying drinking water. It works by applying pressure to push water through a semipermeable membrane, which blocks contaminants such as salts, heavy metals, and microorganisms. This process produces purified water that meets drinking water standards by significantly reducing dissolved solids and impurities.
Reverse osmosis drinking water system design as flows：
Source water quality analysis report: Conductivity 7200us/cm.
Source water: Bore hole water
Output pure water quality can reach Client indicted drinking requirement.
Water temperature：2—35℃
production capacity: 20m3/hr
Voltage and Frequency: 380V/50Hz 3 phase
Recovery rate:60%
Reverse osmosis drinking water system details: (deep well water)
| HY-RO 20m3/hr | |||
| Flow rate | 480m3/day | Recovery rate | 60% |
| Applicable power | 380V/50HZ 3 phase | Rated power | 38KW |
| Feedwater Conductivity | <7200us/cm | freshwater TDS | <200ppm |
| Working pressure | <2-3.0Mpa | operating temperature | 5-45℃ |
| Feedwater residual chlorine | <0.1ppm | Feedwater SDI | <5 |
| Feedwater turbidity | <1NTU | Feedwater PH value | 3-10 |
| RO membrane housing | 8040-5 core,4piece | RO membrane | 20 piece |
| Equipment specification | About 6X1.2X1.6m) | Net weight | / |
| Packing specification(Plywood) | Need to 40ft container | Gross weight | / |
| Oprtion PLC and HMI Brand: Mitsubishi, WEINVIEW. Siemens.
Option pump brand: NP or Grudnfos pump Option membrane: Vontron, LG or Tory. Our conments: NP and vontron membrane have good price and nice quality. |
|||
10m3/hr drinking water system for bottle water 10m3/hr well water for drinking water
Reverse osmosis drinking water system Inquiry Guides
To find the most appropriate for your use, please advise the following information ready
· Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
·Product water purpose(drinking, irrigation, industry process or others)
· Feed Water TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
· Power (110/220/380V/415V/460V, 50 or 60 Hz) 3 phase.
· It is necessary to make water analysis reprot for borehole water,lake water, seawater.
· If soure water is tap water no need end to us TDS or water analysis report.
Quickly discuss and reply you. My whatsapp +86 13798883773, +8613532836525
