Industrial duplex water softener system 80m3ph Ecuador
Duplex softener system industrial Water SoftenerOverview
Water softener purpose:
Operational Continuity: A “one duty, one standby” industrial water softener setup is designed to ensure continuous water softening by having one unit in operation while the other is on standby. This configuration maximizes uptime and provides a backup system in case of maintenance or failure of the primary unit.
water softener system operation:
Continuous Monitoring: The duty unit operates continuously, with automatic controls to initiate regeneration cycles as needed, based on water usage and hardness levels.
softener standby Unit:
Backup Role: The standby unit remains idle but ready to take over immediately if the duty unit requires regeneration or maintenance.
Automatic Switching: The system is designed to automatically switch to the standby unit when the duty unit is offline for regeneration or repair. This ensures an uninterrupted supply of softened water.
80m3ph water softener for Ecuador client adopt one working one stanby.
| HY-Water 80m3/hr | |||
| Flow rate | 80m3/hr | Recovery rate | 100% |
| Applicable power | 380V/50HZ 3 phase | Rated power | 15KW |
| Feedwater hardness | <450ppm | Treated water | 16ppm |
| Working pressure | <0.3-.04Mpa | operating temperature | 5-45℃ |
| Feedwater residual chlorine | <0.1ppm | Feedwater SDI | <5 |
| Feedwater turbidity | <1NTU | Feedwater PH value | 6.5-7.5 |
| Softener vessel size | Φ2000×2600 | Resin voloum | 3150L |
| Auto vavle type | Electrical butterfly | Operation way | PLC with HMI |
| Equipment specification | 5X2X2.6m | Net weight | / |
Water softener inquiry guides
To find the most appropriate for your use, please advise the following information ready
· Product water flow rate ( m3/hr, m3/day, Liter/hr,GPM,GPD etc.)
·Product water purpose(drinking, irrigation, industry process or others)
· Feed Water TDS (Total dissolved solids). Is it from Borehole/salt/brackish/lake water
· Power (110/220/380V/415V/460V, 50 or 60 Hz) 3 phase.
· It is necessary to make water analysis reprot for borehole water,lake water, seawater.
· If soure water is tap water no need end to us TDS or water analysis report.
Quickly discuss and reply you. My whatsapp +86 13798883773, +8613532836525
